Description
product properties：identify AC piles
Equipment size：1700*695*295mm[L*W*T)
Installation method:Wall mounted/floor mounted
“”
Wiring method:Next in line
“”
equipment weight:100KG/130KG
Cable long cable:5m
“”Input voltage:AC380V士15%
“”
Input frequency:50±5HZ
rated power：（60-120）KW
Steady flow accuracy：≤土1%
The output voltage：DC200-700V
Output current：110-440A
rated power：< 2W
Stablization accuracy：≤士5%
Safety standard：GB/T18487-2015
Ripple coefficient：≤+0.5%
Applicable environment：Indoor/outdoor
Operating temperature：-20*~50°C
Working humidity：Air-cooled
Operating altitude：< 2000m
Protection level：IP54
cooling method：air-cooled
Harmonic current：≤5%
Charging efficiency：≥93%
